Interpump

K7

Interpump K7 unloader valve

The Interpump by-pass valve K7 can work with pressures up to 200 bar and with flow rates up to 41 l/min. The K7 is a "zero" valve: it means that the valve is equipped with an automatic system that allows to discharge to the by-pass the residual pressure in the delivery line when the gun is closed. This sophisticated system has many advantages for the operator in terms of safety and comfort. The performances offered by K5 suggest its use on washing systems designed to be used also by non-professional users; especially small pressure washers or self-service car wash systems.

document Download the product sheet

Technical data

Max pressure (bar) 200
Max flow rate (l/min) 41
Body brass
By-pass g 3/8" f

Part numbers

PN Max pressure (bar) FLOW RATE (L/MIN) INLET OUTLET JIT DELIVERY
10ZK70 200 8 - 11 G 3/8" F G 3/8" M
10ZK71 200 11 - 16 G 3/8" F G 3/8" M
10ZK72 200 16 - 25 G 3/8" F G 3/8" M Check
10ZK73 200 25 - 41 G 3/8" F G 3/8" M

MORE INFORMATION

  • Brand: Interpump
  • Made in Italy
