PA

LS 10

LS10 high pressure foamer

PA LS10 foam lance can work with pressures up to 200 bar and flow rates up to 25 l/min. This foamer is designed to dispense foam by working in combination with professional pressure washers. The LS10 foam lance is equipped with an integrated suction system that, thanks to the force of the water under pressure, allows to mix water, air and chemical. The quality of the foam generated is ensured by the special mesh filter placed inside the lance body. The dosage of the chemical can be adjusted by turning the knob positioned at the injector inlet.

document Download the product sheet

Technical data

Max pressure (bar) 200
Max flow rate (l/min) 25
Body brass

Part numbers

PN Ø NOZZLE (MM) INLET SPARE PARTS JIT DELIVERY
1125186050 1,5 G 1/4" F --
1125186065 1,5 G 3/8" M --
1129080253 -- -- sst diaphragm Check
1129080385 -- -- nylon filter Check

MORE INFORMATION

  • Brand: PA
  • Made in Italy
