Hawk plunger pumps - MPX 500 series

The Hawk plunger pumps from the MPX 500 series are designed to work with a maximum pressure of 500 bar and a higher water flow than the one supplied by the most popular 500 bar pumps on the market. In fact, the MPX 500 pumps can reach a maximum water flow rate of 30 l/min at 1450 rpm. These performances make the MPX 500 suitable for use on washing systems designed for industrial cleaning purposes.

document Download the product sheet

Technical data

Max pressure (bar) 500
Flow rate (l/min) from 25 to 36 l/min
Manifold brass
PTO male shaft Ø 30 mm

Part numbers

PN RPM FLOW RATE (L/MIN) MAX PRESSURE (BAR) MAX POWER (KW) JIT DELIVERY
12MPX2550 (MPX2550) 1450-1740 25-30 500 23,8-28,6
12MPX3050 (MPX3050) 1450-1740 30-36 500 28,5-34,2

MORE INFORMATION

  • Brand: Hawk
  • Available with right or left shaft (please specify in case of order)
  • Made in Italy
