Emiltec

HYDROBOX

High pressure box cleaning machine

Hydrobox was born from the need to quickly wash the boxes used for grape harvesting during the harvest period. The HYDROBOX is widely used in various work contexts such as sausage factories, dairies, distribution of fruit and vegetables and other application contexts where there is the need to wash boxes quickly.

The HYDROBOX can be powered by common hot water high pressure cleaners (minimum 150 bar @ 15 l/min) or it can be supplied already equipped with a suitable pumping unit capable of transforming it into an autonomous washing point.

TECHNICAL FEATURES:

  • sliding guides adjustable in width and protruding to facilitate the positioning of the boxes and the pick up after washing;
  • possibility to adjust the working pressure of the nozzles for a better distribution of the water jets on the upper and lower part of the box;
  • high efficiency internal and external rotating washing system with adjustment of the upper nozzles to adapt to any type of box;
  • high performance motor pump unit: 150 bar @ 21 l/min (optional).

document Download the product sheet

Technical data

Suggested pressure (bar) 150 minimum
Suggested flow rate (l/min) 15 minimum
Dimensions (cm) 203x67x112
"L" model dimensions (cm) 203x77x122
Body stainless steel

Part numbers

PN TYPE MOTOR-PUMP UNIT MAXIMUM BOX HEIGHT (CM) MAXIMUM BOX WIDTH (CM) JIT DELIVERY
59HYDROBOX basic not included 35 45
59HYDROBOXCA basic H not included 45 45
59HYDROBOXPLUS plus included* 35 45
59HYDROBOXPLUSCA plus H included* 45 45
59HYDROBOXL basic L not included 45 60
59HYDROBOXCAL basic HL not included 55 60
59HYDROBOXPLUSL plus L included* 45 60
59HYDROBOXPLUSCAL plus HL included* 55 60
*21 l/min @ 150 bar motor-pump unit included

MORE INFORMATION

  • Brand: Emiltec
  • Made in Italy
